Scaffolding Prop

if you need Scaffolding Prop,Steel support,Steel shore prop,Adjustable scaffolding prop,please contact us

Description
An adjustable scaffolding prop consists of internal tube, external tube, prop nut, base plate and top plate.
Adjustable scaffolding prop can be adjusted to any length within its range which is convenient for using.Steel support
With its simple structure, adjustable scaffolding prop is easy to assemble and dismantle which can help to save your time, energy,and cost.
Adjustable scaffolding prop is for supporting concrete slab, beam, timber and formwork which is strong and reliable for interior building construction.
Application: support equipment in construction, mining, tunnel, bridge.
Package: 50pcs/pallet.

Scaffolding prop parts
Product Name Materials size
Inner Tube Q345 48.6±0.2*L *2.3±0.2
Outer Tube Q345 60.5±0.2*L *2.3±0.2
Prop Sleeve Q235 Φ60.2±0.2×L195mm±0.1×t3.2(±0.2)
Prop Nut GCD450 Inner diam
Support Pin Q235 Φ11.5±0.2×L95mm±0.1
Base Q235 140×140×5.5t


Type Outer Tube(mm) Inner tube(mm) adjustable length(mm) Weight (kg)
From To
SPS30 800 800 800 1500 7
V0 1200 1000 1200 2000 9
V1 1700 1800 1800 3200 11
V2 1700 2000 2000 3400 12
V3 1700 2400 2400 3700 13
V4 1700 2600 2600 4000 14
V5 2200 3000 4000 5000 17
V6 3200 3000 4600 6000 19
SS1 3200 3000 3300 6000 19
V7 3200 4000-4600 5100 6900 24
